BORED PILES » MC 45

Main specs overview

  • Model name
  • MC 45
  • Category
  • BORED PILES
  • Max torque
    (KNm)
  • 46
  • Max Diameter
    (mm)
  • 1000
  • Max Depth
    (m)
  • 32
  • Weight
    (ton)
  • 20

More details

Description

The MC 45 has been designed to guarantee better productivity for  drilling of small and medium diameter bored piles, with maximum running economy. Thanks to it’s compact size, the MC 45 is easyily transported with no need to remove the kelly bar.  This significantly allows the customer to reduce transport costs & set-up time, therefore increasing productivity on the jobsite.
The MC 45 is mounted on Caterpillar excavator base, which offers enormous advantages for spare parts and technical assistance.  The cabin is spacious, comfortable and ensures a better working environment for the operator.
The MC 45 can even be mounted with a special CFA application kit.

Technical data

Rotary
Nominal Torque 46 KNm 33,950 lbsft
Nominal Pull-Back/Pull-Down 70 - 60 KN 15,750 - 13,500 lbs
Unloading Speed 130 rpm
Stroke 2.000 mm 6.5 ft
Winches
Main Winch Nominal Pullback 70 KN 15,750 lbs
Secondary Winch Nominal Pullback 25 KN 5,625 lbs
Engine
Brand CATERPILLAR
Model C4.2
Power 67 KW @ 1.850 rpm 90 HP @ 1,850 rpm
Hydraulic System
Hydraulic Oil Tank 150 liters 39.6 gal
Fuel tank 250 liters 66 gal
Crawler
Length 3.750 mm 12.3 ft
Width 2.490 mm 8 ft
Shoes 500 mm 1.6 ft
Weight
Approx weight 17,5 - 20 ton 38,570 - 44,080 lbs

Working characteristics

Works with Augers & Buckets
Max Diameter 1.000 mm 3 ft
Depths 32 m 105 ft
